Statie Totala DTM 624R

Stația totală DTM 624 R4 design compact și ușor de transportat și de configurat. măsurare fără prismă până la 400 de metri.

Producator: DADI Surveying

Caracteristici tehnice :

Distance Measurement

Range:

• Non-prism 400m

• Prism Single prism: 2000m, Three prism:3200m

Accuracy:

Non-prism ±(5mm+3ppm.D)

Prism : ±(3mm+2ppm.D)

Measuring time: Precise model:2s,Track model:0.5s

Number of time Set:  1-99

Meteorologic correction: Input the value and correct automatic

Prism constant: Input the value and correct automatic

Angle Measurement

Method Absolute coding

Minimum reading 1"

Accuracy : 2"

Compensator

System: Single axis photoelectric tilt sensor

Working range : ±3′

Distinguish ability: 1"

Size: 180*175*335mm

Weight: 6.5KG

Working temperature : -20°C-50°
